Dc To Ac 4-12KW Off Grid Solar Panel Power Inverter For Home

Name: Dc To Ac 412KW Off Grid Solar Panel Power Inverter For Home
Brand: Bright
Price: 203 USD

China Dc To Ac 4-12KW Off Grid Solar Panel Power Inverter For Home wholesale

Brand Name : Bright

Model Number : BR-IN-2000

Certification : CE, ROHS, ISO9001

Place of Origin : Xiamen, China

MOQ : 1set

Price : USD203-238

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000sets/month

Delivery Time : 15-25 days after receiving 50% deposit

Packaging Details : Brown carton+wood pallet

Color : Black, white or customized

Input voltage : 130-280V or 160-260V

Output voltage : AC 220V±3%

Output waveform : sine wave

Battery type : lead-acid,lithium-iron,gel,ternary and customized

Nominal voltage of external battery : 12/24/48V

Conversion mode : interactive 5ms

Overload capacity : Maintain 60 seconds when 110%-120%, maintain 10 seconds when 150%

Communication interface : RS-232

Operating environment : temperature: 0-40℃， humidity: 10%-90%

Contact Now

Solar High Efficiency Dc To Ac 4-12KW Off Grid Solar Power system Inverter invertor for home With WIFI

Mode		BR-IN-1000	BR-IN-1500	BR-IN-2000	BR-IN-3000	BR-IN-4000	BR-IN-5000	BR-IN-6000	BR-IN-7000
rated power		1000W	1500W	2000W	3000W	4000W	5000W	6000W	7000W
peak power		3000W	4500W	6000W	9000W	12000W	15000W	18000W	21000W
Input	Voltage	wide input voltage range(130V-280V AV) or narrow input voltage range(160V-260V) is optional
	Frequency	45-65Hz
Ouput	Voltage	AC220V±3%(battery mode)
	Frequency	50/60Hz±1%(battery mode)
Output waveform		Sine wave
Efficiency of the whole machine		＞85%
Battery type		Lead-acid,lithium-iron,gel,ternary and customized
Nominal voltage of external battery		12/24/48VDC		12/24/48VDC		24/48VDC
Max charging current of mains supply		80A(12VDC),40A(24VDC), 20A(48VDC)
Protection		Overloaded,short-circuit, over-temperature, over/low voltage of battery, over/low voltage of mains supply protection
Conversion mode		Interactive 5MS(typical)
Overload capacity		Maintain 60 seconds when 110%-120%, maintain 10 seconds when 150%
Communication interface		RS-232(optional)
Operating environment	Temperature	0-40℃
	Humidity	10%-90%
LWH(mm)		370210170mm		485230210mm		540285210mm
N.W(KG)		?	?	16	21	27	?	?	?

Product description

MPPT design Off Grid Solar Power system Inverter for home use

Features

Solis 1P 4G Single Phase Range

High frequency switching technology - Smaller, smarter

Three MPPT design with precise MPPT algorithm

Over 98.1% Max. effciency

LCD shows the solar capacity.
AC/DC priority modes can be set.

Advantages:

Compared with the high-frequency inverter and the power frequency inverter, the power frequency inverter has the complementary function of the city power, the UPS uninterrupted power supply function; the electrical appliances are constantly powered. Because the built-in high-power transformer (low-frequency transformer) isolates the power amplifier tube, the load capacity is strong, impact resistance; it is not easy to damage, and the service life is long. There is the complementary power supply of the city power inverter; the city power charges the battery, and the inverter can be suitable for various batteries on the market. Customers can define and adjust various parameters by themselves.

Dc To Ac 4-12KW Off Grid Solar Panel Power Inverter For Home

FAQ

1. Q: Can I have sample before formal order?

A: Sure, it will be warmly welcomed.

2. Q: What's the warranty:
A: 24 months for free.

3. Q: What's the payment methods?
A: Usually we accept T/T (Telegraphic Transfer)

4. Q: OEM is available?
A: Yes, OEM is welcomed.
